1. Weighs a wide range of flexible and rigid packs up to 100kg;
2.Excellent processing and weighing speed by FPGA hardware filter with intelligent algorithms;
3.Automatic parameter setting by intelligent product sampling;
4.Ultra-fast dynamic weight tracking and automatic compensation technology to effectively improve the weighing stability;
5.Easy operation by friendly colorful HMI;
6.High capacity operation statistic record with USB data output;
7.Brushless motors & proven conveyor components designed for reliable 24/7 operation
8.High precision structural components and stainless steel 304 frame by CNC tooling.
1. German HBM high speed load cell
2. Japanese Oriental motor
3. Danish Danfoss frequency converter
4. Japanese Omron Optic sensors
5. US Gates synchronous belt
6. Japanese SMC pneumatic unit
7. Weinview industrial touch screen
| Model | FA-CW1200 |
| Brand | Fanchi |
| Weight Range | 0.1-100kg |
| Minimum Scale/Resolution | 1g |
| Best Accuracy(Зσ) | ±20g |
| Max Throughput | 15pcs/min |
| Line Height Options | 450, 500, 550, 600, 650, 700, 750, +/-100mm(can be customized) |
| Weigher Platform Size(WxL) | 1200x1800mm |
| Belt Width | 1200mm |
| Belt Type | PU Anti-static |
| Supply Voltages | 220V/1P/50 or 60Hz |
| Air Supply | 5-8bar(10mm outside dia) |
| Product Memory | 100 |
| Material of Construction | 304 Brushed stainless steel |
| Temperature Range | -10 to 40° C (14 to 104° F) |
| Humidity | 0 to 95% Relative Humidity (Non-condensing) |
| Software Language | English(Spanish/French/Russian, etc optional) |
| Data Retrieval | Via USB Port |
| Certificates | CE/ISO9001/ISO14001 |
